Key Features

• Selectable analogue output: 4–20mA or 0–10V
• Very-low-drift 16-bit D/A converter; 65,535-count external resolution
• 24-bit Delta-Sigma A/D converter; ±0.015% linearity
• 5VDC excitation for up to six 350Ω load cells
• 4- or 6-wire load cell connection; bipolar ±4mV/V input
• Front-panel setup and calibration using a rotary switch and push buttons
• Selectable sampling rates: 80, 200 or 600 SPS
• Running-average digital filtering configurable via free FDC PC software over USB
• Compact DIN-rail enclosure: EN60715, IP20
• 9–32VDC supply; −25 to +70°C operating range
